DeWalt DWS780-QS


Complete your purchase

DeWalt DWS780-QS
DeWalt DWS780-QS
Included accessories
Saw blade
Saw blade
Select alternative
Onderstel voor afkortzagen
Onderstel voor afkortzagen
Select alternative
Construction vacuum
Construction vacuum
Select alternative
5% discount
on the accessories on the accessory
1.255,98 1.236,63
Delivered tomorrow

Product information

Key specs

Pull function
Yes
Tiltable saw head
Tiltable to both sides
Maximum saw width 90° (straight)
345 mm
Maximum saw depth 90° (straight)
110 mm
Saw blade diameter
305 mm

Pros and cons

According to our radial arm saw expert
  • The shadow line system makes sure you can clearly see the cutting line, making it easy to steer the saw blade.
  • Thanks to its 305-millimeter saw blade, you can saw up to 345 millimeters wide and 110 millimeters deep.
  • The saw head can be tilted to 2 sides, so you can make all possible miter cuts.
  • Table extension isn't possible, which makes it trickier to work with large materials.
Product Expert radial arm saws

Description

With the DeWalt DWS780-QS, you're getting a versatile sawing machine. You can saw small profiles like rabbets and grooves, but also larger construction projects and timber construction. When working on large projects, the high, dual stop with adjustable support sections provides the support you need. Use the linearly bearing horizontal rails with bronze conductors for maximum precision when sawing materials of up to 345 millimeters in width. With the miter and slant setting, you can quickly and easily switch from one setting to another. If you want to saw non-ferro metals, use the bar clamps and adjust the saw's rotation speed. With the DWS780-QS, you can carry out virtually any sawing job.

With the DeWalt DWS780-QS, you're getting a versatile sawing machine. You can saw small profiles like rabbets and grooves, but also larger construction projects and timber construction. When working on large projects, the high, dual stop with adjustable support sections provides the support you need. Use the linearly bearing horizontal rails with bronze conductors for maximum precision when sawing materials of up to 345 millimeters in width. With the miter and slant setting, you can quickly and easily switch from one setting to another. If you want to saw non-ferro metals, use the bar clamps and adjust the saw's rotation speed. With the DWS780-QS, you can carry out virtually any sawing job.


Included by default

Included by default

Key specs

Pull function
Yes
Tiltable saw head
Tiltable to both sides
Maximum saw width 90° (straight)
345 mm
Maximum saw depth 90° (straight)
110 mm
Saw blade diameter
305 mm

Included by default

Included by default


DeWalt: schroefboormachine cadeau na registratie

DeWalt: schroefboormachine cadeau na registratie
Wanneer je tussen 1 september 2020 en 31 januari 2021 de DeWalt DWS780-QS aanschaft,...
Wanneer je tussen 1 september 2020 en 31 januari 2021 de DeWalt DWS780-QS aanschaft, kun je een gratis schroefboormachine aanvragen bij DeWalt. Tot 15 februari 2021 kun je jouw actieproduct aanmelden voor de actie van DeWalt. Bekijk de actievoorwaarden (pdf) voor meer informatie.


Alternatives

Specifications

Product

Product number
779321
Manufacturer code
DWS780-QS
Brand
DeWalt
Warranty
2 years
Warranty type
Carry-in warranty
Old product returned for free
Yes

Physical properties

Weight
24,8 kg
Height
47 cm
Depth
77 cm
Width
39,6 cm

Power supply

Power supply type
Grid current
Cable length
2 m
Connection voltage
220 - 240 V
Power
1675 W

Sawing properties

Revolutions per minute (RPM)
3800 rpm
Pull function
Yes
Conductor
Yes
Conductor type
Shadow line
Power source conductor
Via main model
Softstart
Yes
Flipover saw
No
Connection for vacuum
Yes
Type of dust extraction
Dust bag/cup
Saw blade diameter
305 mm
Diameter arbor hole
30 mm
Tiltable saw head
Tiltable to both sides
Maximum saw depth 45° (slant)
63 mm
Maximum saw blade incline left
48 °
Maximum saw width 45° (slant)
345 mm
Maximum saw depth 90° (straight)
110 mm
Maximum saw width 90° (straight)
345 mm
Including underframe
No
Table extension
No
Includes saw blade
Yes
Number of teeth (numerical)
48
Suitable for (surface)
Hard wood , MDF, Plastics, Wood
Saw blade thickness (numerical)
3 mm
Type DIYer
Professional
