AEG TCH74B01FB ComboHob
With a cooktop with an extractor, you need space directly under the cooktop for the extraction system. An oven, cutlery drawer, or regular drawer will no longer directly under the cooktop. There must also be space for the extractor. We won't connect your cooktop for you. If you don't have experience connecting Perilex plugs, call a certified electrician. Make sure to check carefully whether you have a 2-phase connection in your fuse box.
Check here to see if your kitchen is suitable for a cooktop with an extractor.Insure your Cooktop
Coolblue takes care of everything, from taking out an insurance to repairs
For almost all accidents
More coverage in case of damage than your standard warranty
No deductible
How do I insure my Cooktop?
First, add your Cooktop to your shopping cart. On the next page, choose the Protection Plan below. You always have a 30-day return window and pay no deductible in case of damage.
4-year Protection Plan
148,-
one-time5-year Protection Plan
202,-
one-time
Specifications
Product
Product number | 975145 | |
|---|---|---|
Manufacturer code | 949 598 022 | |
Brand | AEG | |
Processing of your defect | At your home | |
Old product returned for free |
General features
Appliance placement | Built-in | |
|---|---|---|
Cooktop heating | Induction | |
Width | 71 cm | |
Height | 22,5 cm | |
Depth | 52 cm | |
Weight | 17,34 kg | |
Color | Black | |
Finish cooktops | Gloss | |
Cooking surface material | Glass | |
Cooktop frame | Beveled glass | |
Cover |
Installation dimensions
Standard cooktops cutout width | 68 cm | |
|---|---|---|
Minimum distance between the cutout and the wall (cooktops) | 0,5 cm | |
Built-in niche width | 68 cm |
Physical properties
Number of settings | 9 | |
|---|---|---|
Flexible cooking zone | ||
Number of flexible cooking zones | 1 | |
Boost function | ||
Max. power of the largest cooking zone | 3,2 kW | |
Keep-warm function | ||
Auto heat-up | ||
Auto shut-off in case of overflow | ||
Temperature control | ||
Pan recognition | ||
Pan size recognition | ||
Residual heat indicator | ||
Temperature setting | Settings | |
Preparation quality | Mid-range | |
Included by default | Installation kit, Manual, Power cord |
User-friendliness
Control options | Slider, Touch keys | |
|---|---|---|
Cooktop controls via oven | ||
Memory function | ||
Safety switch-off | ||
Child safety lock | ||
Overheating protection | ||
All-off button | ||
On/off indicator | ||
Brand-specific technologies | AEG Hob2Hood, AEG MaxiSense |
Electrics
Suitable for plug type | Perilex (5-pin) | |
|---|---|---|
Connector included | ||
Connection to number of phases in the Netherlands | 2 phases (Perilex connector) | |
Connection to number of phases in Germany | 2 phases (3680 - 7360W) | |
Minimum power supply | 7350 W | |
Location of electric connector | Right rear |
Cooking zone properties
Number of cooking zones | 4 | |
|---|---|---|
Cooking zone 1 | Expandable | |
Power output cooking zone 1 | 2,3 kW | |
Diameter cooking zone 1 | 21 cm | |
Cooking zone 2 | Expandable | |
Power output cooking zone 2 | 2,3 kW | |
Diameter cooking zone 2 | 21 cm | |
Cooking zone 3 | Standard | |
Power output cooking zone 3 | 1,4 kW | |
Diameter cooking zone 3 | 14,5 cm | |
Cooking zone 4 | Standard | |
Power output cooking zone 4 | 1,8 kW | |
Diameter cooking zone 4 | 18 cm |
